Products

JSPF800

Applications

- Pressure boosting for domestic and commercial water supply



Characteristics:

- Provide constant pressure for all taps at the same time
- Variable speed helps to save energy
- Quality stainless steel for longer service life
- Protective features ensure the safety of the product


General


Guarantee                                                                                             18 months

Pump type                                                                                            Jet pump


Pump


Self priming                                                                                          7m

Typical noise                                                                                         82dB

Connection                                                                                            inlet G1”, outlet G1”

Temperature of pumped liquid                                                                0-40℃

Maximum capacity                                                                                 60 L/min

Head up to                                                                                            37.5m


Motor


Asynchronous                                                                                       two poles

Protection class                                                                                    IP55

Insulation                                                                                            Class F

Continuous operation                                                                            S1

Maximum ambient temperature                                                             40℃


Constructions


Pump body                                                                                           stainless steel

Mechanical seal                                                                                    Graphite/Silicon carbide/NBR

Bearing                                                                                                Bearing steel

Impeller                                                                                               Sabic PPO

Diffuser                                                                                                Sabic PPO

Motor shaft                                                                                           316  stainless
