General Guarantee 3 years Pump type Centrifugal multistage Pump Self priming 7m Typical noise 64dB Connection inlet G1”, outlet G1” Temperature of pumped liquid 0-40℃ Maximum capacity 60 L/min Head up to 60m Motor Asynchronous two poles Thermal protector inbuilt (single phase) Protection class IP55 Insulation Class F Continuous operation S1 Maximum ambient temperature 40℃ Constructions Suction/discharge mounting Cast iron/Cast brass/Cast stainless steel Mechanical seal Graphite/Silicon carbide/EPDM Bearing Bearing steel by NSK Impeller Sabic PPO/stainless steel Pump housing Stainless Steel Diffuser Sabic PPO Motor shaft 316 stainless |
