MHE 90 Series

Applications

The WENDY MHE pump is an automatic multistage pump specially designed for domestic water pressurization, commercial water supply and small industrial applications. It integrates the automatic controller inside its structure, improving the convenience of use and installation. In addition, the pump can be equipped with a cover to improve its waterproof and ultraviolet protection ability for outdoor use and extend its service life.

Features

- Automatic controller
- Cut-in by setting pressure
- Cut-out by flow
- Timming water supply
- User friendly
- Low noise
- Protection feature such as water shortage, sensor malfunction.
- Withstand 24-hour non-stop running
- Float switch can be connected
- IPX5
- Outdoor protective cover

Constructions

- Impeller: AISI304 / Noryl (Sabic PPO)
- Diffuser: Noryl (Sabic PPO)
- Pump Shaft: AISI316
- Pump housing: AISI304
- Suction & discharge mounting: cast iron
- Bearing: NSK
- Mechanical seal: Graphite, Silicon carbide, NBR, AISI304
